Description

45 Series Central Connector – Horizontal Orientation (90°)

They are 100% compatible with the following manufacturers:

  • 80/20 #14013
  • Bosch Rexroth – 3 842 535 466
  • TSLOTS #659669
  • KATIM® #KAT101055

These connectors require a milling machine service that can be selected in the extrusion machining options.

Dimensions are as follows:

  • A = 45.5mm
  • B = 32.0mm
  • D = Ø16.7mm
  • F = 9.6mm
  • G = 18mm
  • H = 28mm
